Model

HK-Z24/08-S1

Operation control mode

automatic

Max pressure             (MPa)

0.8/1.0

Air flow                 (M³/min)

2.4

Running speed             ( R/min)

2900±50

Drive mode

Belt drive

Exhaust outlet diameter      ( Inch )

1”

Noise                     dB(A)

65±2

Type of motor

Three-phase asynchronous motors

Motor rated output          ( KW)

22KW/30HP（5.5kw/7.5hp x 4 )

Motor frequency            ( HZ )

50

Motor voltage              ( V )

380

Dimension ( L xW x H )              (MM )

1550*1140*1100

Weight                   ( KG )

800
