Model

HK-Z48/08-S1

Operation control mode

automatic

Rated pressure             (MPa)

0.8

Air flow                 (M³/min)

4.8

Running speed             ( R/min)

2900±50

Drive mode

Belt drive

Exhaust outlet diameter      ( Inch )

2”

Noise                     dB(A)

68±2

Type of motor

Three-phase asynchronous motors

Motor rated output          ( KW)

44KW/60HP（5.5kw/7.5hp x 8 )

Motor frequency            ( HZ )

50

Motor voltage              ( V )

380

Dimension ( L xW x H )              (MM )

2150*1450*1630

Weight                   ( KG )

1520
